Telycam Vision+ SE HDMI Wh

Beschrijving

Telycam Vision+ SE HDMI Wh

Telycam Vision+ SE HDMI Wh, 4K PTZ Camera, With auto tracking, Smooth 4K video at up to 60 fps, 12x optical zoom, Versatile connection options such as NDI HX3, HDMI and USB, Integrated AI-supported auto-tracking function, FreeD support for virtual reality productions, Tally light on the plinth front, SSDP for convenient network setup, Audio with 3.5 mm Line-in, Tolerated temperature range during operation: -10 °C ~ 50 °C, Tolerated humidity during operation: =80 %, Dimensions (L × W × H): 220 x 190 x 173 mm, Weight: 1.5 kg, Colour: White@+*Technical specifications:*, Sensor and lens: 1/2.8 inch, 9MP UHD CMOS sensor, 12x optical zoom, Lens: f=3.4mm~40.3 mm, F1.8~F3.6, Horizontal aperture angle: 80.5°(Wide)~7.6°(Tele), Min. Distance: Wide: 1m Tele: 1.5m, Vertical viewing angle: 50.0°~4.4°, Diagonal viewing angle: 88.9°~8.7°, S / N Ratio: = 50 dB@+*Image parameters:*, Noise reduction: 2D & 3D, Min. Brightness: 0.5Lux (50 IRE Max AGC, 1/30, F1.8), White balance: Auto / Manual / ATW / Push / Indoor / Outdoor / Colour Temperature, Exposure: Auto / Manual / Shutter Priority / Iris Priority / Brightness Priority, Anti-Flicker: OFF, 50Hz, 60Hz, Image Flip: supported, Mirroring: supported, Focus: Auto / Manual, Shutter opening: Auto / Manual, Electronic shutter: Auto / Manual, Gamma: supported, Backlight compensation: supported@+*Video formats:*, NDI®HX3: Main Stream: 3840 x 2160 P15~60, 1920 x 1080 P15~60, 1280 x 720 P15~60, 1024 x 576 P15~60, Sub Stream: 640 x 360 P15~30, HDMI: 3840 x 2160 P15~60, 1920 x 1080 P15~60, 1280 x 720 P15~60, 1024 x 576 P15~60, USB Type-C: NV12: 1920 x 1080 P5, 1280 x 720 P15, 1024 x 576P25, 800 x 448 P30, YUYV: 1920 x 1080 P5, 1280 x 720 P15, 1024 x 576P25, 800 x 448 P30, MJPG: 3840 x 2160 P30, 1920 x 1080 P60, 1280 x 720 P60, 1024 x 576 P60, 800 x 448 P60, H264 / H265: 3840 x 2160 P30, 1920 x 1080 P60, 1280 x 720 P60, 1024 x 576 P60, 800 x 448 P60@+*IP streaming:*, Video Encoding: H.264 / H.265, Bitrate Control: variable Bitrate (VBR), Constant bitrate(CBR), Bitrate Range: 1024 Kbps ~ 122800 Kbps, Network Port Speed: 1000M, Protocol: NDI HX3, SRT, HTTP, RTSP, RTMP, ONVIF, VISCA over IP (TCP&UDP), VISCA, PELCO P/D, SSDP, FreeD, NTP, RTP Multicast, WebRTC@+*Pan / Tilt Movement:*, Presets: Remote Controller 10, Serial Port: 256, Accuracy: 0.1°, Pan rotation range: -170° ~ +170°, Tilt otation range: -30° ~ +90°, Pan rotation speed: 0.1° ~ 120°/s, Tilt rotation speed: 0.1° ~ 80°/s@+*I / O Interface:*, Control Port: RS232(RS485), NDI HX, Video Port: NDI HX3, HMDI, USB Type-C, Audio Port: Stereo 3.5 mm linear input, Tally: supported, POE+: supported, Daisy chain: supported, Input voltage: DC12V
